5 Inch Monitor Wireless Rearview Camera Signal System For Recording

  • 1
  • 2
  • 3

Brand Name : TX

Model Number : FX11F

Certification : FCC CE ROHS

Place of Origin : China

MOQ : 1 set

Price : negotiable

Payment Terms : Western Union, MoneyGram, L/C, T/T

Supply Ability : 1000pcs/week

Delivery Time : 5-8 days

Packaging Details : color box

Screen Size : 5 Inch color Screen

Material : Metal

Warranty : 12 months

Transmission Distance(barrier free) : 300m(984ft)

Transmission Power : 23dB

Night vision distance : 4-5m

Camera Weight : 90g

Resolution : 800*480

Contact Now

5 Inch Monitor Wireless Rearview Camera Signal System For Recording

Backup Camera 5 Inch Monitor Wireless Signal System For Car Driving/Recording

Specification:

Monitor

LCD Size:5 Inch Color Monitor
Resolution:800 x 3(RGB)x 480
Brightness:1000 cd/m
TV System:PAL/NTSC
Transmitted Power:24±1dBm@Max
Operating Frequency:2.4GHz~2.4835GHz
RX Sensitivity-85dBm@10%PER
Spread SpectrumFHSS
Video CompressionH.264
Latency160ms
Transmitting Distance984ft line of sight
TF CardMin.8G Max.128G
Power Supply:DC+12V~+24V
Operating temperature:-20℃~+70℃
Storage temperature:-30℃~+80℃
Size132.5x89.5x22.5mm


Camera

Image Sensor1/2.7’’COMS HD
Viewing Angle160°
AGCAuto
BLCAuto
White BalanceAuto
Operation Frequency2.4GHz--2.4835GHz
Spread SpectrumFHSS
RF Bit Rate12Mbps
Minimum Illumination0Lux
Night vision distance4-5m
Power supplyDC 10-18V
Waterproof ratingIP69K
Operating Temperature-20℃--70℃,RH85% MAX
Storage Temperature-30℃--80℃,RH85% MAX
Size85x28x27.5mm
Weight90g


Features:

1. First 5 Inch 720P Dual-channel digital high-definition wireless DVR set
2. Resolution: 800*480 Brightness: 1000cd/M.
3. 720P H.264 HD DVR Recording ,support 128G SD Card max,support playback online.
4. Support split two-way display and video on the same screen.
5. Camera power cord designed with flat line, power by connecting license plate light, can work for rear recording a long time
6. Transmission power is 23DBM,camera built-in antenna.
7. 120 degree full-glass wide angle lens, 200W(1080P) Pixel sensor,High definition-can help avoid incidents and accidents abrasion effectively.
8. IP69K waterproof.can work at raining day and extreme weather:-20℃--70℃
9. Smart auto photosensitive and light complement ,6pcs highlight LED light help driving at night.
10. Apply to Vehicles: mini car, pickup, SUV,RV, Trailer RV.

Competitive advantage:

1. Stable quality(CE,FCC,ROHS)
2. Most competitive price
3. On time delivery
4. All products must test one by one waterproof resistance and high/low temperature resistance
5. Warranty: 12 months
6. OEM,ODM welcome

Notices:

  • Please use this product within the specified voltage range.
  • Pay attention to the positive poles of the power cord. If the positive and negative sides are connected in reverse, it may burn out.
  • If smoke or burning smell is detected, please disconnect the power immediately.
